Quectel M66 R2.0

Ultra-compact

Quad-band GSM/GPRS Module

Build a Smarter World

M66 R2.0 is an ultra-compact quad-band GSM/GRPS module using LCC castellation packaging. Based on the latest 2G chipset,

it has the optimal performance in SMS & data transmission and audio service even in harsh environment. The highly compact

17.7mm × 15.8mm × 2.3mm profile makes it a perfect selection for size sensitive applications.

M66 R2.0 adopts surface mounted technology, making it an ideal solution for durable and rugged designs. The low profile

and small size of LCC package ensure it can be easily embedded into size-constrained applications, and provides reliable

connectivity with applications. This kind of package is ideally suited for large-scale manufacturing which has strict

requirements for cost and efficiency.

The compact form factor, low power consumption and extended temperature range make M66 R2.0 a best choice for M2M

applications such as wearable devices, automotive, industrial PDA, personal tracking, wireless POS, smart metering,

telematics, and so on.

Key

Benefits

Extremely compact quad-band GSM/GPRS module

Easier soldering process with LCC package

Power consumption as low as 1.3mA

Support Voice and QuecFOTA® functions

Embedded powerful Internet service protocols, multiple Sockets &

IP addresses

Quad-band

GPRS Multi-slot

Class 12

Highly Compact Size

LCC Package

Embedded Internet

Services Protocols

Quectel Enhanced

AT Commands

Digital Audio

EMAIL US: info@quectel.com

VISIT US: www.quectel.com

Extended Temperature

Range: -40°C ~ +85°C

Bluetooth 3.0

Rev: V1.1 | Status: Released
