SARA-R5 series - Data sheet

UBX-19016638 - R06

Electrical specifications

Page 26 of 43

C1-Public

4.2.3 Current consumption

Mode

Condition

Tx power

Module

Min

Typ11 Max

Unit

Power-off mode

Average current value

(power-off mode)

SARA-R510S

0.5

SARA-R500S

SARA-R510M8S

PSM deep-sleep mode

Average current value

(PSM deep-sleep mode)

SARA-R510S

0.5

SARA-R500S

SARA-R510M8S

Cyclic idle / active mode

(+UPSV=1)

Average current value

(rock bottom)

All

1.0

Average current value

(DRX = 2.56 s, PTW = 20.48 s,

eDRX = 655.36 s)

All

1.1

Average current value

(DRX = 2.56 s, PTW = 20.48 s,

eDRX = 81.92 s)

All

1.2

Average current value

(DRX = 2.56 s, PTW = 5.12 s,

eDRX = 20.48 s)

All

1.2

Average current value

(DRX = 2.56 s, no eDRX)

All

1.5

Average current value

(DRX = 1.28 s, no eDRX)

All

2.0

Active mode

(+UPSV=0)

Average current value

(DRX = 1.28 s)

All

LTE Cat M1 connected mode Average current value

(Tx / Rx data transfer)

Minimum

(–50 dBm)

All

0 dBm

All

100

8 dBm

All

115

14 dBm

All

140

20 dBm

All

170

Maximum

(23 dBm)

All

195

Maximum current value

(During Tx only)

Maximum

(23 dBm)

All

395

Table 11: VCC current consumption of SARA-R5 series modules with GNSS off

11 Typical values with matched antenna, VCC = 3.8 V
