DocID026122 Rev 5
21/54
TDA7786, TDA7786M
Function description
53
Figure 9. I2S interface 16-bit
Figure 10. I2S interface 32/24/20/16-bit
2.16
Audio sample rate converter
The TDA7786x is equipped with internal sample rate converters (SRC) that can be
configured to modify the sampling frequency of outgoing and incoming digital audio both in
the master and in the slave SAI mode (the native audio sampling frequency of the
TDA7786x is 45.6 kHz).
The SRC is able to automatically detect the input and output sampling rates and includes a
sample clock jitter rejection function which can be enabled separately. The input signal
word-width is 20 bits, while the output signal word width can be selected as 20 bits or 16
bits. In order to properly assist in the conversion, the SRC is coupled to self-adjusting low-
pass filters.
