Phone: +1.408.494.0330 l Fax: +1.408.494.0325 l WWW.KYCON.COM l 0915

IP67 Connectors: GM67X-CS Series

Cable Side, IP67 Cable Mount

(Must Be Used with GM67X Series Box Side Part)

Product Features

IP67

Cable Mount

Cable O.D. Options Available

Performance Specifications

Materials and Finish

Housing Material

Polycarbonate, UL 94V-0 Rated, Black Color

Seal

Silicone, UL 94HB Rated, Red or Blue Color

Nut Material

Polycarbonate, UL 94V-0 Rated, Black Color

Gasket Material

Silicone, UL 94HB Rated, Red Color

Note:

*Must be used with GM67X box side part

*To be used when assembling Cat 5 cable

*Kycon can offer custom cable assemblies (mins will apply)

Series

GM67X-CS - Cable Mount IP67 Cable Side Component

Cable Seal

R - Seal for Cable Outer Diameter of 5.5 mm - 7 mm

B - Seal for Cable Outer Diameter of 7 mm - 9.5 mm

Contact Kycon for Other Options

-R: Recommended Cable O.D.: 5.5 mm to 7 mm

-B: Recommended Cable O.D.: 7 mm to 9.5 mm

Nut

Seal

Housing

Gasket

GM67X-CS Series

Dimensions in mm

Generated Part Number

Part Number Builder

Series

Shield

Option

2D Drawing

Check Stock

IGES

Solder Profile

STEP

Request a Sample

CofC RoHS Compliant

CofC REACH Compliant

UL Plastic File

Certificate of Origin

Send Us An Email

3D PDF

GM67X-CS-R

GM67X-CS

R

Click here for our assembly videos
