LM193, LM293, LM293A, LM393, LM393A, LM2903, LM2903V, LM393B, LM2903B

www.ti.com

SLCS005AB – OCTOBER 1979 – REVISED DECEMBER 2019

Product Folder Links: LM193 LM293 LM293A LM393 LM393A LM2903 LM2903V LM393B LM2903B

Submit Documentation Feedback

Typical Characteristics, LM393B and LM2903B (continued)

TA = 25°C, VS = 5 V, RPULLUP = 5.1k, CL = 15 pF, VCM = 0 V, VUNDERDRIVE = 100 mV, VOVERDRIVE = 100 mV unless otherwise

noted.

Figure 18. Input Offset Voltage

vs. Supply Voltage at 85°C

Figure 19. Input Offset Voltage

vs. Supply Voltage at 125°C

Figure 20. Input Bias Current

vs. Supply Voltage

Figure 21. Input Bias Current

vs. Input Voltage at 5V

Figure 22. Input Bias Current

vs. Input Voltage at 12V

Figure 23. Input Bias Current

vs. Input Voltage at 36V
