NEC's EA MODULATOR

INTEGRATED InGaAsP MQW DFB

LASER DIODE MODULE

FOR 2.5 Gb/s ULTRALONG-REACH

360, 600, 240 km DWDM APPLICATIONS

NX8564LE

NX8565LE

NX8566LE

SERIES

FEATURES

•

INTEGRATED ELECTROABSORPTION MODULATOR

•

VERY LOW DISPERSION PENALTY:

Over 360 km (6480 ps/nm), NX8564LE-BC/CC

Over 600 km (10800 ps/nm), NX8565LE-BC/CC

Over 240 km (4320 ps/nm), NX8566LE-BC/CC

• LOW MODULATION VOLTAGE

• AVAILABLE FOR DWDM WAVELENGTH

BASED ON ITU-T RECOMMENDATION

100 GHz grid, refer to

ORDERING INFORMATION

NEC's NX8564/8565/8566LE Series is an Electro-Absorption

(EA) modulator integrated, 1550 nm Multiple Quantum Well

(MQW) structured Distributed Feed-Back (DFB) laser diode.

The module is capable of 2.5 Gb/s applications of over 360

km, 600 km, 240 km ultralong-reach and available for Dense

Wavelength Division Multiplexing (DWDM) wavelengths

based on ITU-T recommendations, enabling a wide range of

applications.

DESCRIPTION

California Eastern Laboratories
