M95512-W, M95512-R

22/31

Table 12. DC Characteristics (M95512-W, Device Grade 6)

Note: 1. The information contained in Table 12. is subject to change without previous notice.

Table 13. DC Characteristics (M95512-R)

Note: 1. The information contained in Table 13. is subject to change without previous notice.

Symbol

Parameter

Test Condition

(in addition to those in Table 8.)

Min.(1)

Max.(1)

Unit

ILI

Input Leakage Current

VIN = VSS or VCC

± 2

µA

ILO

Output Leakage Current

S = VCC, VOUT = VSS or VCC

± 2

µA

ICC

Supply Current

C=0.1VCC/0.9VCC at 10MHz,

VCC = 5V, Q = open

C = 0.1VCC/0.9VCC at 5MHz,

VCC = 2.5V, Q = open

C = 0.1VCC/0.9VCC at 1MHz,

VCC = 2.5V, Q = open

ICC1

Supply Current

(Standby Power mode)

S = VCC, VCC = 2.5V, VIN = VSS or VCC

µA

S = VCC, VCC = 5V, VIN = VSS or VCC

VIL

Input Low Voltage

–0.45

0.3 VCC

VIH

Input High Voltage

0.7 VCC

VCC+1

VOL

Output Low Voltage

IOL = 1.5 mA, VCC = 2.5 V

0.4

VOH

Output High Voltage

IOH = –0.4 mA, VCC = 2.5V

0.8VCC

Symbol

Parameter

Test Condition(1)

(in addition to those in Table 9.)

Min.(1)

Max.(1)

Unit

ILI

Input Leakage Current

VIN = VSS or VCC

± 2

µA

ILO

Output Leakage Current

S = VCC, VOUT = VSS or VCC

± 2

µA

ICC

Supply Current

C=0.1VCC/0.9VCC at 2 MHz,

VCC = 1.8 V, Q = open

1mA

ICC1

Supply Current

(Standby Power mode)

S = VCC, VIN = VSS or VCC, VCC = 1.8 V

3µA

VIL

Input Low Voltage

–0.45

0.3 VCC

VIH

Input High Voltage

0.7 VCC

VCC+1

VOL

Output Low Voltage

IOL = 0.15 mA, VCC = 1.8 V

0.3

VOH

Output High Voltage

IOH = –0.1 mA, VCC = 1.8 V

0.8 VCC
