FEATURE

1.

Metal ultra low and stable TCR performance

2.

High power rating and compact size

3.

High reliability and stability

4.

Reduced size of final equipment

5.

RoHS exemption free & Halogen free & Lead free

6.

Inductance below 1nH

APPLICATION



Power supply



PDA



Digital meter



Computer



Automotives



Battery charger



DC-DC power converter

DESCRIPTION

The resistors are constructed in a high grade low resistive metal body. The resistive layer is covered with a

protective coat and printed a resistance marking code over it. Finally, the two external end terminations are

added. For ease of soldering the outer layer of these end terminations is a Lead free terminations.

Fig 1. Construction of Chip-R
