THEORY OF OPERATION

The HMC521ALC4 is a MMIC mixer in a 24-terminal, RoHS

compliant, ceramic LCC package. The device can be used as

either an image reject mixer or a single sideband upconverter.

The mixer uses two standard, double balanced mixer cells and a

90° hybrid fabricated in a GaAs, MESFET process. This device

is a much smaller alternative to a hybrid style image reject mixer

and a single sideband upconverter assembly. The HMC521ALC4

eliminates the need for wire bonding, allowing the use of

surface-mount manufacturing techniques. When used as an

image reject mixer, the HMC521ALC4 downconverts radio

frequencies between 8.5 GHz and 13.5 GHz to intermediate

frequencies between dc and 3.5 GHz. When used as single

sideband upconverter, the HMC521ALC4 upconverts

intermediate frequencies between dc and 3.5 GHz to RF

between 8.5 GHz and 13.5 GHz.
