3216FF

Fast-acting Chip™ surface mount fuse

Technical Data 3001

Effective May 2017

Recommended Pad Layout - mm (in)

Dimension - mm/inches

Drawing Not to Scale

Time-Current Curve

Current in Amps

Packaging

Packaging Code Pre x

Description

TR

3000 fuses on 8mm tape-and-reel on a 7 inch (178mm) reel per EIA Standard RS481
