Technical Data 4368

Effective May 2017

Supersedes June 2009

Product features

•

High current carrying capacity, high permeability

•

Magnetically shielded, low EMI

•

Frequency range up to 1 MHz

•

5.3 mm x 6.1 mm footprint surface mount

package in a 4.95 mm height

•

Iron powder core material

•

Halogen free, lead free, RoHS compliant

Applications

•

Voltage Regulator Module (VRM)

•

Multi-phase regulators

•

Desktop and server VRMs and EVRDs

•

Point-of-load (POL) modules

•

Notebook regulators

•

Data networking and storage systems

•

Graphics cards

•

Battery power systems

Environmental data

•

Storage temperature range (component):

-40 °C to +125 °C

•

Operating temperature range: -40 °C to +125 °C

(ambient plus self-temperature rise)

•

Solder reflow temperature:

J-STD-020 (latest revision) compliant

HCP0605

High current power inductors

Pb HALOGEN

HF

FREE

Surface Mount Device
