Technical Data 10433

Effective September 2015

HCM1307

High current power inductors

Description

•

High current carrying capacity

•

Low core losses

•

Magnetically shielded, low EMI

•

Frequency range up to 1MHz

•

Inductance range from 0.47μH to 3.3μH

•

Current range from 15 to 63 amps

•

14.2 x 13.0mm footprint surface mount

package in a 6.5mm height

•

Iron powder core material

•

Halogen free, lead free, RoHS compliant

Applications

•

Multi-phase regulators

•

Voltage Regulator Modules (VRMs)

•

Distributed power systems DC-DC converters

•

Desktop and server VRMs and EVRDs

•

Point-of-Load (POL) modules

•

Field Programmable Gate Array

(FPGA) DC-DC converters

•

Battery power systems

•

High current power supplies

•

Data networking and storage systems

Environmental Data

•

Storage temperature range (Component):

-55°C to +125°C

•

Operating temperature range: -55°C to +125°C

(ambient + self-temperature rise)

•

Solder reflow temperature: J-STD-020D

compliant

Pb

HALOGEN

HF

FREE
