background image
Product description:
•
Halogenfree,leadfree,
RoHScompliant
•
125°Cmaximumtotaltemperature
operation
•
2.7x2.2x1.0/1.2mmmaximum
surfacemountpackage
•
Magneticallyshielded,lowEMI
•
Inductancerangefrom
0.47µHto10.0µH
•
Currentrangefrom1.1to4.8amps
Applications:
•
Mobile/smartphones
•
Handheld/mobileequipment
•
Digitalcameras
•
Mediaplayers
•
GPS
•
MP3Players
•
Tablets/e-readers
Environmental data:
•
Storagetemperaturerange(Component):
-40°Cto+125°C
•
Operatingtemperaturerange:-40°Cto+125°C
(ambient+self-temperaturerise)
•
Solderreflowtemperature:J-STD-020D
compliant
Packaging:
•
Suppliedintapeandreelpackaging,3000
partsper7”diameterreel
MPI2520
High Current, Low Profile, Miniature Power Inductors
TechnicalData10199
EffectiveJanuary2014
HALOGEN
HF
FREE
Pb
Discontinued,
Effective
September
15,
2016
or until
inventory
is depleted.
Recommended
replacement
MPI25-V2
