Technical Data 10448

Effective October 2015

FP1108L1 and FP1108L2

High frequency, high current power inductors

Description

•

High current carrying capacity

•

Low core loss

•

Ultra low DCR

•

Inductance range from 105nH to 150nH

•

Current range from 48 to 81 amps

•

11.0 x 8.2mm footprint surface mount package

in an 8.3mm height

•

Ferrite core material

•

Halogen free, lead free, RoHS compliant

Applications

•

Servers

•

Multi-phase and Vcore regulators

•

Voltage Regulator Modules (VRMs)

•

Desktop VRMs and EVRDs

•

Data networking and storage systems

•

Graphics cards and battery power systems

•

Point-of-Load modules

Environmental Data

•

Storage temperature range (Component):

-40°C to +125°C

•

Operating temperature range: -40°C to +125°C

(ambient + self-temperature rise)

•

Solder reflow temperature: J-STD-020D

compliant

Pb

HALOGEN

HF

FREE
