background image
Technical Data 4342
Effective June 2017
Supersedes August 2009
Product features
•
7.2 x 11.0 x 7.5mm surface mount package
•
Ferrite core material
•
High current carrying capacity, low core losses
•
Controlled DCR tolerance for sensing circuits
•
Inductance range from 70nH to 510nH
•
Current range from 18 amps to 140 amps
•
Frequency range up to 2MHz
Applications
•
Storage temperature range (component):
-40 °C to +125 °C
•
Operating temperature range: -40 °C to +125 °C
(ambient plus self-temperature rise)
•
Solder reflow temperature:
J-STD-020 (latest revision) compliant
FP1107
High frequency, high current power inductors
Pb HALOGEN
HF
FREE
•
Multi-phase regulators
•
Voltage Regulator Module (VRM)
•
Desktop and server VRMs and EVRDs
•
Data networking and storage systems
•
Graphics cards and battery power systems
•
Point-of-load modules
•
DCR sensing
Environmental data
SMD Device
