ULN2012

Preliminary

LINEAR INTEGRATED CIRCUIT

UNISONICTECHNOLOGIESCO.,LTD

4 of 6

www.unisonic.com.tw

QW-R113-020.a



ABSOLUTE MAXIMUM RATING

PARAMETER

SYMBOL

RATINGS

UNIT

Output Sustaining Voltage

VOUT

-0.5 ~ 50

Input Voltage

VIN

-0.5 ~ 30

Clamp Diode Reverse Voltage

Output Current

IOUT

600

mA /ch

Clamp Diode Forward Current

600

Power Dissipation

1.25 (Note 2)

Junction Temperature

+125

°C

Operating Temperature

TOPR

-40 ~ +85

°C

Storage Temperature

TSTG

-55 ~ +150

°C

Notes: 1. Absolute maximum ratings are those values beyond which the device could be permanently damaged.

Absolute maximum ratings are stress ratings only and functional device operation is not implied.

2. On PCB (Test Board: JEDEC 2s2p)



ELECTRICAL CHARACTERISTICS (TA=25°C, unless otherwise specified)

PARAMETER

SYMBOL

TEST

CIRCUIT

TEST CONDITIONS

MIN

TYP

MAX UNIT

Output Leakage Current

ICEX

VCE =50V, VIN=6.0V

μA

IOUT =200mA, IIN =350μA

1.1

1.3

IOUT =350mA, IIN =500μA

1.3

1.6

Collector-Emitter Saturation Voltage VCEO(SAT)

IOUT =500mA, IIN=600μA

1.7

1.9

Input Current (Output On)

IIN (ON)

VIN=17V

0.82

1.25

Input Current (Output Off)

IIN (OFF)

IC=500µA

μA

Input Voltage (Output On)

VIN(ON)

VCE=2V, IC=500mA

VR=50V, TA=25°C

μA

Clamp Diode Reverse Current

VR=50V, TA=85°C

100

μA

IF=350mA

1.7

2.0

Clamp Diode Forward Voltage

IF=500mA

2.1

2.5

Input Capacitance

CIN

Turn-On Delay

tON

0.5Ein to 0.5 Eout

0.45

μs

Turn-Off Delay

tOFF

0.5Ein to 0.5 Eout

0.2

μs
