CK4,0-ED-2,50BU AG Order No.: 1663284

http://eshop.phoenixcontact.de/phoenix/treeViewClick.do?UID=1663284

PHOENIX CONTACT Deutschland GmbH

Page 2 / 4

http://www.phoenixcontact.de

Feb 2, 2011

Mechanical characteristics

Conductor cross-section

2.5 mm²

Connection cross-section AWG

Stripping length of the individual wire

9 mm (9.6 mm (4-6 mm2))

Insertion/withdrawal cycles

≥ 500

General characteristics

Type

Individual female contact

Series

HC-M-03

Material data

Contact material

Copper alloy

Contact surface material

hard-silver plated

Certificates / Approvals

Certification

GOST, UL

Accessories

Item

Designation

Description

Tools

1662735

CK4,0-EWZ

Contact removal tool, for rotated CK-4,0-... contacts

1205846

CRIMPFOX-4,0-ED-2,50

Crimping pliers, for CK 4.0... contacts, for conductor cross

sections 1.5 - 2.5 mm²

1205859

CRIMPFOX-4,0-ED-6,00

Crimping pliers, for CK 4.0... contacts, for conductor cross

sections 3.0 - 6.0 mm²
