AXGPS5050 Rev.2

www.axtal.com

Roemerring 9

Drawing D0

fon: +49 (6261) 939834

D-74821 Mosbach

Page 2(4)

fax: +49 (6261) 939836

Germany

E-mail: info@axtal.com

GmbH & Co. KG

Parameter

min.

typ.

max.

Unit

Condition

Lock Detect

0.5

0

3.3

0.4

V

V

Locked

Not locked

11.4

12.0

12.6

V

Current consumption (steady state)

300

mA

@ +25°C

Current consumption (warm-up)

600

mA

@ +25°C

Operating temperature range

-40

+75

°C

Enclosure size (see drawing) (LxWxH)

50x50x25 max.

mm

Drawing number

AXZ10.01104.01

RF Connectors (GPS IN & 1PPS IN/OUT)

MMCX female

Weight

100

g

Notes:

1.

Terminology and test conditions are according to IEC60679-1 and MIL-PRF-55310, unless otherwise stated

2.

See software manual for AXGPS5050

Absolute Maximum Ratings

Parameter

min.

max.

Unit

Condition

-0.5

V

Storage Temperature

-55

+85

°C

Ordering Code

Model

Revision

Frequency [MHz]

AXGPS5050

Rev.2

10.000

Example: AXGPS5050_Rev.2 – 10.000 MHz

Environmental Conditions, Handling and Testing

Parameter

Procedure

Source

Processing

Application Note AXAN-012

www.axtal.com

Parameter

Procedure

Condition

Electrostatic discharge (ESD)

THD devices

IEC60749-26

HBM

2000 V

SMD devices

IEC60749-27

MM

200 V

Washable

Yes

No

RoHS- Compliant

Yes

No
