S486

CMOS IC

UNISONIC TECHNOLOGIES CO., LTD

3 of 12

www.unisonic.com.tw

QW-R502-074.D



ABSOLU T E M AX I M U M RAT I N G (TA=25°

С)

PARAMETER

SYMBOL

RATINGS

UNIT

Supply voltage (Note 2)

VCC

Input Voltage

VIN

-0.3V ~ VCC+0.3V

Output Short Circuit to VCC or GND

Continuous(Note 3)

SOP-8

0.71

Power Dissipation (TJ=150°

С)

MSOP-8

0.58

Junction Temperature

+150

Operating Temperature

TOPR

-40 ~ +85

Storage Temperature

TSTG

-65 ~ +150

Notes: 1. Absolute maximum ratings are those values beyond which the device could be permanently damaged.

Absolute maximum ratings are stress ratings only and functional device operation is not implied.

2. All voltage values are measured with respect to the ground pin.

3. Attention must be paid to continuous power dissipation (VDD x 300mA). Exposure of the IC to a short circuit

for an extended time period is dramatically reducing product life expectancy.



T H ERM AL DAT A

PARAMETER

SYMBOL

RATINGS

UNIT

SOP-8

175

С/W

Junction to Ambient

MSOP-8

θJA

215

С/W



RECOM M EN DED OPERAT I N G CON DI T I ON S

PARAMETER

SYMBOL

RATINGS

UNIT

Supply Voltage

VCC

2 ~ 5.5

ACTIVE

1.5

≤VSTB≤VCC

Standby Voltage Input

STANDBY

VSTB

GND

≤VSTB≤0.4(Note)

Load Resistor

≥16

Ω

RL = 16 ~ 100

Ω

400

Load Capacitor

RL > 100

Ω

100

Junction to Ambient

θJA

150

℃

Note: The minimum current consumption (ISTB) is guaranteed at GND for the whole temperature range.
