UL52C

Preliminary

CMOS IC

UNISONICTECHNOLOGIESCO.,LTD

3 of 6

www.unisonic.com.tw

QW-R125-079.a



ABSOLUTE MAXIMUM RATING (Ambient temperature is 27°C if there is no special instruction)

PARAMETER

SYMBOL

RATINGS

UNIT

ESD Voltage Withstand

VESD

>2000

Operating Temperature

TOPR

-20 ~ +125

°C

Storage Temperature

TSTG

-40 ~ +150

°C

Note: Absolute maximum ratings are those values beyond which the device could be permanently damaged.

Absolute maximum ratings are stress ratings only and functional device operation is not implied.



ELECTRICAL CHARACTERISTICS (Ambient temperature is 27°C if there is no special instruction)

PARAMETER

SYMBOL

TEST CONDITIONS

MIN

TYP

MAX UNIT

OUT1 Input Voltage

VOUT1

6.5

Output Current

IOUT

100

REXT Port Voltage

VREXT

VOUT1=VOUT4=10V

0.9

OUT1/ OUT2 Port Withstand Voltage

VDS_BV1

IOUT1=IOUT2=0

450

OUT3/ OUT4 Port Withstand Voltage

VDS_BV2-4

IOUT3=IOUT4=0

250

IOUT Accuracy

dIOUT

IOUT=10~100mA

±5

Over-Temperature Protection Point (Note 1)

TSC

140

°C

Note: When the junction temperature is over 140°C, the output current of UL52C will be reduced
