SMD Power Inductor

CDB87D78

Note： This specification is subject to change without notice. Please contact your nearest sales office for updated information when placing an order.

Page 2 of 3

Ver.0.0 (November 10, 2016)

www.sumida.com

Electrical Characteristics

Part No.

Inductance

(mH)

Within

D.C.R (

Ω)

Max. (Typ.)

at 20℃

Saturation Current (A)

(Typ.) *1

Temperature Rise

Current (A) Typ.

*2

at 25℃

at 100℃

at 125℃

CDB87D78NP-R15MC

0.15 ±20％

0.20m(0.19m)

(95.0)

(87.0)

(81.0)

(72.0)

Measuring frequency inductance at 1MHz.

*1 Saturation current: DC current which becomes inductance value drop by 20% from the initial value.

*2 Temperature rise current: The value of D.C. current when the temperature of coil becomes ⊿T=40℃(Ta=20℃).
