Power Supply Terminals

19

20.7

Note1 : Sold by the reel.(Sea above table for number of Packaging.)

Note2 : This component is used only with applicable HRS housings.

Note1 : Sold by the reel.(See above table for number of Packaging.)

Note2 : This component is used only with applicable HRS housings.

GT7-2022SCF(70)

GT7A-2022SCF(70)

757-0001-1 70

757-0003-7 70

Part No.

HRS No.

5,000 pcs/reel

3,000 pcs/reel

Material

Plating

Conductor Size (AWG) Outer Diameter

Packaging

Copper

alloy

Tin plating

20 to 22 AWG

Ø1.4 to 2.4

Ø2.6 to 3.1

YES

RoHS

GT7-2022PCF(70)

GT7A-2022PCF(70)

757-0002-4 70

757-0004-0 70

Part No.

HRS No.

5,000 pcs/reel

3,000 pcs/reel

Material

Plating

Conductor Size (AWG) Outer Diameter

Packaging

Brass

Tin plating

20 to 22 AWG

Ø1.4 to 2.4

Ø2.6 to 3.1

YES

RoHS

GT13SH Series

Part No.

HRS No.

Material

Color

Packaging RoHS

GT13SH-1/1S-HU

763-0048-7 00

PBT

Light Gray

1

YES

GT13SH-1/1S-HU(A)

763-0059-3 00

Brown

Note : GT7-2022SCF(70) or GT7A-2022SCF(70) is used for power supply terminals.

F Housing (1 Coaxial + 1 Power contact)

F Connector Terminals

Terminals for M Connector
