LXXLD20

Preliminary

CMOS IC

UNISONICTECHNOLOGIESCO.,LTD

4 of 7

www.unisonic.com.tw

QW-4502-701.c



ABSOLUTE MAXIMUM RATING (unless otherwise specified)

PARAMETER

SYMBOL

RATINGS

UNIT

Supply Voltage (VCNTL to GND)

VCNTL

-0.3 ~ +7

Supply Voltage (VIN to GND)

VIN

-0.3 ~ +3.3

EN and FB to GND

VI/O

-0.3 ~ VCNTL+0.3

POK to GND

VPOK

-0.3 ~ +7

Power Dissipation

Junction Temperature

150

°С

Storage Temperature

TSTG

-65 ~ +150

°С

Note: Absolute maximum ratings are those values beyond which the device could be permanently damaged. Absolute

maximum ratings are stress ratings only and functional device operation is not implied.



RECOMMENDED OPERATING CONDITIONS

PARAMETER

SYMBOL

RATINGS

UNIT

Supply Voltage

Control

VCNTL

3.1 ~ 6

Supply Voltage

Input

VIN

1.1 ~ 3.3

Output Voltage

VCNTL=3.3±5%

VOUT

0.8 ~ 1.2

VCNTL=5.0±5%

+0.8 ~ VIN-0.2

Output Current

IOUT

0 ~ 2

Junction Temperature

-25 ~ +125

°С



THERMAL DATA

PARAMETER

SYMBOL

RATINGS

UNIT

Junction to Ambient (Note 1)

θJA

°C/W

Junction to Case (Note 2)

θJC

°C/W

Notes: 1. θJA is measured with the component mounted on a high effective thermal conductivity test board in free air.

The exposed pad of HSOP-8 is soldered directly on the PCB.

2. The Thermal Pad Temperature is measured on the PCB copper area connected to the thermal pad of

package.
