1 / 6 page

https://www.phoenixcontact.com/pi/products/2903364

07/23/2018 Page 1 / 6

Relay Module - RIF-0-RSC-24DC/ 1AU - 2903364

Please be informed that the data shown in this PDF Document is generated from our Online Catalog. Please find the complete data in the user's

documentation. Our General Terms of Use for Downloads are valid

(http://phoenixcontact.com/download)

Pre-assembled relay module with screw connection, consisting of: relay base with ejector and multi-layer gold

contact relay. Contact type: 1 N/O contact. Input voltage: 24 V DC

Key Commercial Data

Packing unit

10 STK

GTIN

4046356731973

Technical data

Note

Utilization restriction

EMC: class A product, see manufacturer's declaration in the download

area

Dimensions

Width

6.2 mm

Height

84 mm

Depth

68 mm

Coil side

Nominal input voltage UN

24 V DC

Input voltage range in reference to UN

see diagram

Typical input current at UN

9 mA

Typical response time

5 ms

Typical release time

8 ms

Coil voltage

24 V DC

Protective circuit

Damping diode

Operating voltage display

Yellow LED

Power dissipation for nominal condition

0.22 W
