Relay Module - RIF-0-RSC-12DC/ 1AU - 2903365

Technical data

Connection data input side

Conductor cross section solid

0.5 mm² ... 4 mm²

Conductor cross-section solid (2 conductors with same cross section)

0.5 mm² ... 1.5 mm²

Conductor cross section flexible

0.5 mm² ... 2.5 mm²

0.5 mm² ... 2.5 mm² (Ferrules without plastic sleeve)

0.5 mm² ... 1.5 mm² (Ferrule with plastic sleeve)

Conductor cross section flexible (2 conductors with same cross section) 0.5 mm² ... 1.5 mm²

0.5 mm² ... 1 mm² (TWIN ferrule with plastic sleeve)

Conductor cross section AWG

20 ... 12 (solid)

20 ... 14 (flexible)

Torque

0.5 Nm ... 0.6 Nm

Connection data output side

Connection name

Contact side

Connection method

Screw connection

Stripping length

7 mm

Conductor cross section solid

0.5 mm² ... 4 mm²

Conductor cross-section solid (2 conductors with same cross section)

0.5 mm² ... 1.5 mm²

Conductor cross section flexible

0.5 mm² ... 2.5 mm²

0.5 mm² ... 2.5 mm² (Ferrules without plastic sleeve)

0.5 mm² ... 1.5 mm² (Ferrule with plastic sleeve)

Conductor cross section flexible (2 conductors with same cross section) 0.5 mm² ... 1.5 mm²

0.5 mm² ... 1 mm² (TWIN ferrule with plastic sleeve)

Conductor cross section AWG

20 ... 12 (solid)

20 ... 14 (flexible)

Torque

0.5 Nm ... 0.6 Nm

General

Test voltage relay winding/relay contact

Operating mode

100% operating factor

Degree of protection

IP20 (Relay base)

RT III (Relay)

Mechanical service life

Mounting position

any

Assembly instructions

In rows with zero spacing

Standards and Regulations

Standards/regulations

DIN EN 50178

Rated insulation voltage

250 V AC

Rated surge voltage

6 kV

Insulation

safe isolation

Degree of pollution

2

Overvoltage category

III
