20 / 39 page ![]() ADRF6518 Data Sheet Rev. A | Page 20 of 39 REGISTER MAP AND CODES The filter frequency, amplifier gains, filter bypass mode, and offset correction loops can be programmed using the SPI interface. Table 5 provides the bit map for the internal 15-bit register of the ADRF6518. Table 4. Filter Mode and Power Mode Options B9 Filter Bypass Filter 0 VGA low power; filter off VGA low power; filter low power 1 VGA high power; filter off VGA low power; filter high power Table 5. Register Map MSB LSB B15 B14 B13 B12 B11 B10 B9 B8 B7 B6 B5 B4 B3 B2 B1 Filter frequency code and filter bypass mode Power mode Digital gain code DC offset disable Code = 1 dB corner in MHz For example, 31 MHz = 011111 (MSB first) Use 000000 for filter bypass mode 0: low power 1: high power Use 1 for filter BW > 31 MHz, in filter mode Use 1 for channel BW > 60 MHz, in filter bypass mode VGA1 gain 00: 15 dB 01: 12 dB 10: 9 dB 11: 9 dB VGA2 gain 00: 21 dB 01: 18 dB 10: 15 dB 11: 12 dB VGA3 gain 00: 21 dB 01: 18 dB 10: 15 dB 11: 12 dB Postamp 0: 3 dB 1: 9 dB 0: enable 1: disable |
|
