Data Sheet

AD8336

Rev. F | Page 5 of 27

ABSOLUTE MAXIMUM RATINGS

Table 2.

Parameter

Rating

Supply Voltage (VPOS, VNEG)

±15 V

Input Voltage (INPP, INPN)

VPOS, VNEG

Gain Voltage (GPOS, GNEG)

VPOS, VNEG

PWRA

5 V, GND

VGAI

VPOS + 0.6 V, VNEG − 0.6 V

Power Dissipation

VS ≤ ±5 V

0.43 W

±5 V < VS ≤ ±12 V

1.12 W

Operating Temperature Range

±3 V < VS ≤ ±10 V

−55°C to +125°C

±10 V < VS ≤ ±12 V

−55°C to +85°C

Storage Temperature Range

−65°C to +150°C

Lead Temperature (Soldering 60 sec)

300°C

Thermal Data1

θJA

58.2°C/W

θJB

35.9°C/W

θJC

9.2°C/W

ΨJT

1.1°C/W

ΨJB

34.5°C/W

4-layer JEDEC board, no airflow, exposed pad soldered to printed circuit board.

Stresses at or above those listed under Absolute Maximum

Ratings may cause permanent damage to the product. This is a

stress rating only; functional operation of the product at these

or any other conditions above those indicated in the operational

section of this specification is not implied. Operation beyond

the maximum operating conditions for extended periods may

affect product reliability.
