OUTLINE DIMENSIONS

SEATING

PLANE

0.30

0.23

0.18

0.203 REF

0.80

0.75

0.70

1.89

1.74

1.59

0.50 BSC

0.20 MIN

0.60

0.45

0.30

0.55

0.40

0.30

BOTTOM VIEW

4

1

5

8

3.25

3.00

2.75

2.25

2.00

1.75

TOP VIEW

0.05 MAX

0.02 NOM

EXPOSED PAD

PIN 1 INDEX

AREA

FOR PROPER CONNECTION OF

THE EXPOSED PAD, REFER TO

THE PIN CONFIGURATION AND

FUNCTION DESCRIPTIONS

SECTION OF THIS DATA SHEET

PIN 1

INDIC ATOR AREA OPTIONS

(SEE DETAIL A)

DETAIL A

(JEDEC 95)

Figure 38. 8-Lead Lead Frame Chip Scale Package [LFCSP]

3 mm × 2 mm Body and 0.75 mm Package Height

(CP-8-23)

Dimensions shown in millimeters

ORDERING GUIDE

Temperature Range

Package Description

Package Option

Branding

ADL5315ACPZ-R7

–40°C to +85°C

8-Lead LFCSP

CP-8-23

Q0

ADL5315ACPZ-WP

–40°C to +85°C

8-Lead LFCSP

CP-8-23

Q0

ADL5315-EVAL

Evaluation Board
