13 / 44 page

Data Sheet

AD8364

Rev. C | Page 13 of 44

–60

–50

–40

–30

–20

–10

2.5

–2.5

2.0

1.5

1.0

0.5

–0.5

–1.0

–1.5

–2.0

INPUT AMPLITUDE (dBm)

Figure 27. OUT[A, B] Voltage and Log Conformance vs. Input Amplitude at

2.5 GHz, Typical Device, ADJ[A, B] = 1.1 V, Sine Wave, Differential Drive,

Balun = Murata LDB182G4520C-110

–60

–50

–40

–30

–20

–10

2.5

–2.5

2.0

1.5

1.0

0.5

–0.5

–1.0

–1.5

–2.0

INPUT AMPLITUDE (dBm)

Figure 28. Distribution of OUT[A, B] Voltage and Error over Temperature

After Ambient Normalization vs. Input Amplitude for at Least 15 Devices

from Multiple Lots, Frequency = 2.5 GHz, ADJ[A, B] = 1.1 V, Sine Wave,

Differential Drive, Balun = Murata LDB182G4520C-110

0.20

–0.20

–60

0.15

0.10

–50

–40

–30

–20

–10

INPUT AMPLITUDE (dBm)

–0.15

–0.10

–0.05

0.05

Figure 29. Distribution of [OUTA – OUTB] Voltage vs. Input Amplitude over

Temperature for at Least 15 Devices from Multiple Lots, Frequency = 2.5 GHz,

ADJ[A, B] = 1.1 V, Sine Wave, Differential Drive, Balun = Murata

LDB182G4520C-110

–60

–50

–40

–30

–20

–10

2.5

–2.5

2.0

1.5

1.0

0.5

–0.5

–1.0

–1.5

–2.0

INPUT AMPLITUDE (dBm)

OUTP

OUTN

Figure 30. OUT[P, N] Voltage and Log Conformance vs. Input Amplitude at

2.5 GHz, with B Input Held at −25 dBm and A Input Swept, Typical Device,

ADJ[A, B] = 1.1 V, Sine Wave, Differential Drive, Balun = Murata

LDB182G4520C-110 (Note that the OUTP and OUTN Error Curves Overlap)

–60

–50

–40

–30

–20

–10

2.5

–2.5

2.0

1.5

1.0

0.5

–0.5

–1.0

–1.5

–2.0

INPUT AMPLITUDE (dBm)

–5

–1

–2

–3

–4

Figure 31. Distribution of [OUTP − OUTN] Voltage and Error over

Temperature After Ambient Normalization vs. Input Amplitude for at Least

15 Devices from Multiple Lots, Frequency = 2.5 GHz, ADJ[A, B] =1.1 V, Sine

Wave, Differential Drive, PIN Ch. B = −25 dBm, Channel A Swept

RF INPUT AT INLA (dBm)

–40

–35

–30

–25

–20

–15

–10

–5

–6

–4

–2

–12

–10

–8

–22

–20

–18

–16

–14

–24

REF

+1dB

+2dB

–1dB

–2dB

+10DEG

+20DEG

–10DEG

–20DEG

+30DEG

–30DEG

SERIES NAME INDICATES THE POLARITY AND

MAGNITUDE OF THE DEVIATION APPLIED TO

THE INHA INPUT, RELATIVE TO THE INLA INPUT,

AS REFERENCED TO THE REF SIGNAL.

Figure 32. Log Conformance vs. Input Amplitude at Various Amplitude and

Phase Balance Points, 2.500 GHz, Typical Device, ADJ[A, B] = 1.1 V, Sine

Wave, Differential Drive
