Level 13 (LO Power +13 dBm) 20 to 750 MHz

Frequency Mixer

High IP3

Demo Board MCL P/N: TB-02+

Suggested PCB Layout (PL-051)

Maximum Ratings

Pin Connections

REV. A

M151107

ADE-751MH+

ED-14942/1

DJ/CP/AM

151018

ADE-751MH+

CASE STYLE: CD541

Outline Dimensions (

)

inch

mm

Outline Drawing

Electrical Schematic

Permanent damage may occur if any of these limits are exceeded.

Electrical Specifications at 25°C

Parameter

Min.

Typ.

Max.

Unit

Frequency Range, RF

20

—

750

MHz

Frequency Range, LO

50

—

780

MHz

Frequency Range, IF

DC

—

250

MHz

Conversion Loss

—

6.6

8.2

dB

LO to RF Isolation

28

42

—

dB

LO to IF Isolation

27

40

—

dB

IP3

—

26

—

dBm

RF Input Power at 1 dB Compression

—

+9

—

dBm

+RoHS Compliant

The +Suffix identifies RoHS Compliance. See our web site

for RoHS Compliance methodologies and qualifications

Features

• high IP3, 26 dBm typ.

• low conversion loss, 6.6 dB typ.

• good L-R isolation, 42 dB typ.

• low profile package

• aqueous washable

• protected by U.S. Patent 6,133,525

Applications

• cellular

LO

6

RF

4

IF

3

GROUND

1,2,5

A

B

C

D

E

F

G

.272

.310

.220

.100

.082

.055

.100

6.91

7.87

5.59

2.54

2.08

1.40

2.54

H

J

K

L

wt

.030

.026

.065

.300

grams

0.76

0.66

1.65

7.62

0.15

Operating Temperature

-40°C to 85°C

Storage Temperature

-55°C to 100°C

RF Power

200mW

IF Current

40mA

PCB Land Pattern

Suggested Layout,

Tolerance to be within ±

� .002

Frequency

(MHz)

Conversion

Loss

(dB)

Isolation

L-R

(dB)

Isolation

L-I

(dB)

VSWR

RF Port

(:1)

VSWR

LO Port

(:1)

IP3

(dBm)

RF

LO

LO

+13dBm

LO

+13dBm

LO

+13dBm

LO

+13dBm

LO

+13dBm

LO

+13dBm

Typical Performance Data

20.10

50.10

6.93

60.76

55.47

1.34

1.66

28.44

50.10

80.10

6.88

56.69

55.03

1.32

1.72

35.88

100.10

130.10

6.90

52.19

54.66

1.32

1.62

31.42

150.10

180.10

6.78

48.80

53.10

1.30

1.65

33.64

200.10

230.10

6.70

47.06

52.49

1.29

1.60

39.63

250.10

280.10

6.60

45.46

51.28

1.27

1.69

29.76

300.10

330.10

6.52

44.41

50.47

1.26

1.68

27.42

350.10

380.10

6.45

43.32

48.63

1.25

1.77

29.22

400.10

430.10

6.44

42.55

48.18

1.24

1.74

25.94

450.10

480.10

6.42

42.02

45.27

1.23

1.86

33.16

500.10

530.10

6.43

41.52

46.06

1.23

1.80

30.52

550.10

580.10

6.34

40.75

42.85

1.19

1.88

25.31

600.10

630.10

6.42

41.02

40.16

1.17

1.89

30.05

650.10

680.10

6.43

40.62

39.98

1.16

2.03

27.89

700.10

730.10

6.48

40.11

40.27

1.15

2.05

29.10

710.10

740.10

6.43

40.00

40.09

1.13

2.07

28.51

720.10

750.10

6.41

39.86

40.01

1.12

2.07

28.59

730.10

760.10

6.43

39.68

39.84

1.11

2.07

28.40

740.10

770.10

6.44

39.52

39.59

1.11

2.09

27.29

750.10

780.10

6.44

39.32

39.39

1.10

2.08

25.42
