Metal Alloy Current Sensors

ELECTRICAL CHARACTERISTICS

Type

Rating

Power

(W)

Max.

Rating

Current

(A) Max.

Overload

Current

(A) Max.

T.C.R

(ppm/°C)

Resistance Range (mΩ)

Operating

Temperature

Range

Tolerance

±1%, ±2%, ±5%

CTCSS3921

9

212.13

474.34

0.2mΩ:≤±200

0.3mΩ:≤±150

0.2; 0.3

-55~170°C

5

158.11

353.55

0mΩ:≤3800

0; 0.2; 0.3; 0.5

0.2mΩ:≤±200

0.3mΩ:≤±150

0.5mΩ:≤±100

4

63.25

141.42

1.0mΩ;2.0mΩ:≤±75

1; 2

3

31.62

70.71

3.0mΩ;4.0mΩ:≤±75

3; 4

2

20

44.72

5.0mΩ:≤±50

5

CTCSS5931

10

223.61

447.21

0.2mΩ:≤±100

0.2

7

187.08

374.17

0.2mΩ;0.3mΩ:≤±100

0.2; 0.3

6

109.54

244.95

0.5mΩ:≤±100

0.5

5

70.71

158.11

1.0mΩ;2.0mΩ:≤±75

1; 2

4

36.51

81.65

3.0mΩ:≤±75

3

Note: When ordering, please specify tolerance code. Tolerance: F= ±1%, G= ±2%, J= ±5%

PowerDeratingCurve:OperatingTemperatureRange:-55~170°C

Forresistorsoperatedinambienttemperatures70°C,powerratingshallbederatedinaccordancewiththecurvebelow:

RatingCurrent:TheresistorshallhaveaDCcontinuousworkingcurrentoraRMS(RootMeanSquare)ACcontinuousworkingcurrentat

commercial-linefrequencyandwaveformcorrespondingtothepowerrating,asdeterminedfromthefollowing:

Remark:I:RatingCurrent(A),P:RatingPower(W),R:Resistence(Ω)




