168
Speed signal /2
– Speed-proportional, square-wave signal for external monitoring of the fan motor speed
– 2, 3, or 6 pulses per revolution
– Open-collector signal output
– Extremely wide operating voltage range
– Easy adaptation to user interface
– Connection via separate cable
– The sensor signal also serves as a major comparison variable for setting and maintaining
the setpoint speed for interactive or controlled cooling with one or more interconnected
fans.
Electrical hookup
All voltages measured to ground.
External load resistor Ra / US / UBS required.
Signal data
