Features

• Protects against dust and contaminants

• Protects against physical damage

• Nickel Plated Body

Applications

• General Purpose Laboratory Use

• Test and Measurement

.

Description

Pasternack’s PE6240 connector dust cap has an F interface and a male gender. Our F male dust cap is a non-shorting

design with a nickel plated body to ensure durability. The Pasternack non-shorting F connector cap is part of over 40,000 RF,

microwave and millimeter wave products that ship the same day.

RF connector dust caps are essential for precision connectors, protecting them from dust, corrosion and potential damage

especially to test and measurement equipment. Specific RF connector cap models come with a chain to prevent loss or

misplacement. Internal short connector cap versions are available to protect equipment from a spike in current caused by

electrostatic discharge (ESD).

Mechanical Specifications

Configuration

Connector

F Male Non-Shorting

.

Hex Size

7/16 inch

Description

Material

Plating

Body

Brass

Nickel

Gasket

Silicone Rubber

.

Size

Length

0.33 in [8.38 mm]

Width

0.43 in [10.92 mm]

.

Weight

0.0455 lbs [20.64 g]

Not RoHS Compliant

Click the following link (or enter part number in “SEARCH” on website) to obtain additional part information including price,

inventory and certifications: F Male Non-Shorting Dust Cap PE6240

PE6240 REV 1.1

F Male Non-Shorting Dust Cap

Shorts and Caps Technical Data Sheet

PE6240
