Features

• Protects against dust and contaminants

• Protects against physical damage

• Passivated Stainless Steel Body

• Internally Shorted

• Chain Included

Applications

• General Purpose Laboratory Use

• Test and Measurement

• ESD Protection

.

Description

Pasternack’s PE6194 RF connector dust cap has a 2.4mm interface and a male gender. Our 2.4mm male dust cap is a

shorting design with a passivated stainless steel body to ensure durability. The Pasternack shorting 2.4mm connector cap

comes with a 3.5 inch chain and is part of over 40,000 RF, microwave and millimeter wave products that ship the same day.

RF connector dust caps are essential for precision connectors, protecting them from dust, corrosion and potential damage

especially to test and measurement equipment. Specific RF connector cap models come with a chain to prevent loss or

misplacement. Internal short connector cap versions are available to protect equipment from a spike in current caused by

electrostatic discharge (ESD).

Mechanical Specifications

Configuration

Connector

2.4mm Male Shorting

Chain Option

3.5 in Chain

.

Hex Size

5/16 inch

Description

Material

Plating

Contact

Beryllium Copper

Gold

Body

Passivated Stainless Steel

Coupling Nut

Passivated Stainless Steel

Gasket

Silicone Rubber

Chain

Stainless Steel

.

Size

Length

0.59 in [14.99 mm]

Width

0.315 in [8.00 mm]

.

Weight

0.01 lbs [4.54 g]

RoHS Compliant

REACH Compliant

12/17/2015

Click the following link (or enter part number in “SEARCH” on website) to obtain additional part information including price,

inventory and certifications: 2.4mm Male Shorting Dust Cap With 3.5 Inch Chain PE6194

PE6194 REV 1.1

2.4mm Male Shorting Dust Cap With 3.5 Inch Chain

Shorts and Caps Technical Data Sheet

PE6194
