Configuration

• SMA Female Connector

• MIL-STD-348

• 50 Ohms

• Straight Body Geometry

• Solder Cup Interface Type

• Solder Attachment

• Bulkhead

Features

• Gold Plated Contact

• Contact plating according to MIL-G-45204

Applications

• General Purpose Test

• Rack and Panel Mount Applications

.

Description

Pasternack’s PE4536 SMA female bulkhead mount connector solder attachment solder cup terminal, .350 inch D hole is

part of our full line of RF components available for same-day shipping. This SMA bulkhead connector allows designers to

create external connections on their product enclosures, and can be used in a variety of other rack mount and panel mount

applications.

Our SMA female bulkhead connector PE4536 datasheet specifications and drawing with dimensions are shown below in

this PDF. Pasternack’s broad catalog of RF, microwave and millimeter wave connectors allows designers to configure and

customize their signal connections however they like. Whether the need is to provide an I/O for a board design, or simply

create a custom cable assembly configuration, Pasternack has the right connector for the job. Pasternack can also expertly

build your custom cable connector assemblies for you and ship same-day.

Mechanical Specifications

Size

Length

0.845 in [21.46 mm]

Width/Dia.

0.435 in [11.05 mm]

.

Weight

0.013 lbs [5.9 g]

.

Material Specifications

Description

Material

Plating

Contact

Gold

MIL-G-45204

Insulation

PTFE

Body

Passivated Stainless Steel

QQ-P-35

.

Click the following link (or enter part number in “SEARCH” on website) to obtain additional part information including price,

inventory and certifications: SMA Female Bulkhead Mount Connector Solder Attachment Solder Cup Terminal, .350 inch D

Hole PE4536

PE4536 REV 1.2

SMA Female Bulkhead Mount Connector Solder

Attachment Solder Cup Terminal, .350 inch D Hole

RF Connectors Technical Data Sheet

PE4536
