Mitsubishi microcomputers
M16C / 62A Group
SINGLE-CHIP 16-BIT CMOS MICROCOMPUTER
Timers’ functions for three-phase motor control
106
Timer B2
Timer A4 output
U phase
U phase
Dead time
Carrier wave
Signal wave
A carrier wave of sawtooth waveform
mn
p
Note: Set to sawtooth modulation mode and to three-phase mode 0.
U phase
output signal
U phase
output signal
The three-phase
shift register shifts
in synchronization
with the falling
edge of timer A4.
Trigger signal for
timer Ai start
(timer B2 overflow
signal)
Interrupt occurs.
Rewriting the value of timer A4.
Rewriting three-phase
output buffer register
Data transfer is made from the three-
phase buffer register to the three-
phase shift register in step with the
timing of the timer B overflow.
Interrupt occurs.
Rewriting the value of timer A4.
o
Figure 1.15.9. Timing chart of operation (4)
