11.0 Voltage Level Monitor (VLM) (Continued)
183
www.national.com
11.5.2
Voltage Event Status Register 0 (VEVSTS0)
This register indicates which of the corresponding eight VLM events has occurred.
Location:
Offset 00h
Type:
RO
11.5.3
Voltage Event Status Register 1 (VEVSTS1)
This register indicates which of the corresponding VLM events has occurred.
Location:
Offset 01h
Type:
RO
Bit
76543210
Name
VSB
ALARM
Event
Status
AVI6
ALARM
Event
Status
AVI5
ALARM
Event
Status
AVI4
ALARM
Event
Status
AVI3
ALARM
Event
Status
AVI2
ALARM
Event
Status
AVI1
ALARM
Event
Status
AVI0
ALARM
Event
Status
Reset
00000000
Bit
Description
7
VSB ALARM Event Status. This channel measures the internal VSB power, using VSB/2.
0: Voltage level within limits (default)
1: High or low limit exceeded
6-0 Analog Voltage Inputs 6-0 ALARM Event Status
0: Voltage level within limits (default)
1: High or low limit exceeded
Bit
765432
1
0
Name
Reserved
TMS3
ALERT or
OTS Event
Status
TMS2
ALERT or
OTS Event
Status
TMS1
ALERT or
OTS Event
Status
AVDD
ALARM
Event
Status
VBAT
ALARM
Event
Status
VDD
ALARM
Event
Status
Reset
0
00000
0
0
Bit
Description
7-6 Reserved
5
TMS3 ALERT or OTS Event Status
0: Voltage level within limits (default)
1: OTS, high or low limit exceeded
4
TMS2 ALERT or OTS Event Status
0: Voltage level within limits (default)
1: OTS, High or low limit exceeded
3
TMS1 ALERT or OTS Event Status
0: Voltage level within limits (default)
1: OTS, High or low limit exceeded
