PIC18F2585/2680/4585/4680

DS39625C-page 282

Preliminary

23.2.2

DEDICATED CAN TRANSMIT

BUFFER REGISTERS

This section describes the dedicated CAN Transmit

Buffer registers and their associated control registers.

TXBnCON: TRANSMIT BUFFER n CONTROL REGISTERS [0

≤ n ≤ 2]

Mode 0

R/C-0

R-0

R/W-0

U-0

R/W-0

TXBIF

TXABT(1)

TXLARB(1)

TXERR(1)

TXREQ(2)

—

TXPRI1(3)

TXPRI0(3)

Mode 1, 2

R/C-0

R-0

R/W-0

U-0

R/W-0

TXBIF

TXABT(1)

TXLARB(1)

TXERR(1)

TXREQ(2)

—

TXPRI1(3)

TXPRI0(3)

bit 7

bit 0

bit 7

TXBIF: Transmit Buffer Interrupt Flag bit

= Transmit buffer has completed transmission of message and may be reloaded

= Transmit buffer has not completed transmission of a message

bit 6

TXABT: Transmission Aborted Status bit(1)

= Message was aborted

= Message was not aborted

bit 5

TXLARB: Transmission Lost Arbitration Status bit(1)

= Message lost arbitration while being sent

= Message did not lose arbitration while being sent

bit 4

TXERR: Transmission Error Detected Status bit(1)

= A bus error occurred while the message was being sent

= A bus error did not occur while the message was being sent

bit 3

TXREQ: Transmit Request Status bit(2)

= Requests sending a message. Clears the TXABT, TXLARB and TXERR bits.

= Automatically cleared when the message is successfully sent

bit 2

Unimplemented: Read as ‘0’

bit 1-0

TXPRI1:TXPRI0: Transmit Priority bits(3)

= Priority Level 3 (highest priority)

= Priority Level 2

= Priority Level 1

= Priority Level 0 (lowest priority)

Note 1: This bit is automatically cleared when TXREQ is set.

2: While TXREQ is set, Transmit Buffer registers remain read-only. Clearing this bit in

software while the bit is set will request a message abort.

3: These bits define the order in which transmit buffers will be transferred. They do not alter

the CAN message identifier.

Legend:

C = Clearable bit

R = Readable bit

W = Writable bit

U = Unimplemented bit, read as ‘0’

-n = Value at POR

‘1’ = Bit is set

‘0’ = Bit is cleared

x = Bit is unknown
