Preliminary

DS39625C-page 403

PIC18F2585/2680/4585/4680

25.2

Extended Instruction Set

In addition to the standard 75 instructions of the PIC18

instruction set, PIC18F2585/2680/4585/4680 devices

also provide an optional extension to the core CPU

functionality.

The

added

features

include

eight

additional instructions that augment indirect and

indexed addressing operations and the implementation

of Indexed Literal Offset Addressing mode for many of

the standard PIC18 instructions.

The additional features are disabled by default. To

enable them, users must set the XINST Configuration

bit.

The instructions in the extended set can all be

classified as literal operations, which either manipulate

the File Select Registers or use them for indexed

addressing. Two of the instructions, ADDFSR and

SUBFSR

, each have an additional special instantiation

for using FSR2. These versions (ADDULNK and

SUBULNK

) allow for automatic return after execution.

The extended instructions are specifically implemented

to optimize re-entrant program code (that is, code that

is recursive or that uses a software stack) written in

high-level languages, particularly C. Among other

things,

they

allow

users

working

high-level

languages to perform certain operations on data

structures more efficiently. These include:

• dynamic allocation and de-allocation of software

stack space when entering and leaving

subroutines

• function pointer invocation

• software stack pointer manipulation

• manipulation of variables located in a software

stack

A summary of the instructions in the extended instruc-

tion set is provided in Table 25-3. Detailed descriptions

are provided in Section 25.2.2 “Extended Instruction

Set”. The opcode field descriptions in Table 25-1 apply

to both the standard and extended PIC18 instruction

sets.

25.2.1

EXTENDED INSTRUCTION SYNTAX

Most of the extended instructions use indexed

arguments, using one of the File Select Registers and

some offset to specify a source or destination register.

When an argument for an instruction serves as part of

indexed addressing, it is enclosed in square brackets

(“[ ]”). This is done to indicate that the argument is used

as an index or offset. MPASM™ Assembler will flag an

error if it determines that an index or offset value is not

bracketed.

When the extended instruction set is enabled, brackets

are also used to indicate index arguments in bit-

oriented and byte-oriented instructions. This is in

addition to other changes in their syntax. For more

details, see Section 25.2.3.1 “Extended Instruction

Syntax with Standard PIC18 Commands”.

TABLE 25-3:

EXTENSIONS TO THE PIC18 INSTRUCTION SET

Note:

The instruction set extension and the

Indexed Literal Offset Addressing mode

were designed for optimizing applications

written in C; the user may likely never use

these instructions directly in assembler.

The syntax for these commands is pro-

vided as a reference for users who may be

reviewing code that has been generated

by a compiler.

Note:

In the past, square brackets have been

used to denote optional arguments in the

PIC18 and earlier instruction sets. In this

text and going forward, optional arguments

are denoted by braces (“{ }”).

Mnemonic,

Operands

Description

Cycles

16-Bit Instruction Word

Status

Affected

MSb

LSb

ADDFSR

ADDULNK

CALLW

MOVSF

MOVSS

PUSHL

SUBFSR

SUBULNK

f, k

zs, fd

zs, zd

f, k

Add literal to FSR

Add literal to FSR2 and return

Call subroutine using WREG

Move zs (source) to

1st word

fd (destination) 2nd word

Move zs (source) to

1st word

zd (destination) 2nd word

Store literal at FSR2,

decrement FSR2

Subtract literal from FSR

Subtract literal from FSR2 and

return

1110

0000

1110

1111

1110

1111

1110

1000

0000

1011

ffff

1011

xxxx

1010

1001

ffkk

11kk

0001

0zzz

ffff

1zzz

xzzz

kkkk

ffkk

11kk

kkkk

0100

zzzz

ffff

zzzz

kkkk

None
