PIC18F2585/2680/4585/4680

DS39625C-page 374

Preliminary

BTFSC

Bit Test File, Skip if Clear

Syntax:

BTFSC f, b {,a}

Operands:

≤ f ≤ 255

≤ b ≤ 7

∈ [0,1]

Operation:

skip if (f<b>) = 0

Status Affected:

None

Encoding:

1011

bbba

ffff

Description:

If bit ‘b’ in register ‘f’ is ‘0’, then the next

instruction is skipped. If bit ‘b’ is ‘0’, then

the next instruction fetched during the

current instruction execution is discarded

and a NOP is executed instead, making

this a two-cycle instruction.

If ‘a’ is ‘0’, the Access Bank is selected. If

‘a’ is ‘1’, the BSR is used to select the

GPR bank (default).

If ‘a’ is ‘0’ and the extended instruction set

is enabled, this instruction operates in

Indexed Literal Offset Addressing

mode whenever f

≤ 95 (5Fh).

See Section 25.2.3 “Byte-Oriented and

Bit-Oriented Instructions in Indexed

Literal Offset Mode” for details.

Words:

Cycles:

1(2)

Note:

3 cycles if skip and followed

by a 2-word instruction.

Q Cycle Activity:

Decode

Read

Process

Data

operation

If skip:

operation

If skip and followed by 2-word instruction:

operation

Example:

HERE

FALSE

TRUE

BTFSC

FLAG, 1, 0

Before Instruction

address (HERE)

After Instruction

If FLAG<1>

address (TRUE)

If FLAG<1>

address (FALSE)

BTFSS

Bit Test File, Skip if Set

Syntax:

BTFSS f, b {,a}

Operands:

≤ f ≤ 255

≤ b < 7

∈ [0,1]

Operation:

skip if (f<b>) = 1

Status Affected:

None

Encoding:

1010

bbba

ffff

Description:

If bit ‘b’ in register ‘f’ is ‘1’, then the next

instruction is skipped. If bit ‘b’ is ‘1’, then

the next instruction fetched during the

current instruction execution is discarded

and a NOP is executed instead, making

this a two-cycle instruction.

If ‘a’ is ‘0’, the Access Bank is selected. If

‘a’ is ‘1’, the BSR is used to select the

GPR bank (default).

If ‘a’ is ‘0’ and the extended instruction

set is enabled, this instruction operates

in Indexed Literal Offset Addressing

mode whenever f

≤ 95 (5Fh).

See Section 25.2.3 “Byte-Oriented and

Bit-Oriented Instructions in Indexed

Literal Offset Mode” for details.

Words:

Cycles:

1(2)

Note: 3 cycles if skip and followed

by a 2-word instruction.

Q Cycle Activity:

Decode

Read

Process

Data

operation

If skip:

operation

If skip and followed by 2-word instruction:

operation

Example:

HERE

FALSE

TRUE

BTFSS

FLAG, 1, 0

Before Instruction

address (HERE)

After Instruction

If FLAG<1>

address (FALSE)

If FLAG<1>

address (TRUE)
