PIC18F2585/2680/4585/4680

DS39625C-page 368

Preliminary

ADDWFC

ADD W and Carry bit to f

Syntax:

ADDWFC

f {,d {,a}}

Operands:

≤ f ≤ 255

∈ [0,1]

Operation:

(W) + (f) + (C)

→ dest

Status Affected:

N,OV, C, DC, Z

Encoding:

0010

00da

ffff

Description:

Add W, the Carry flag and data memory

location ‘f’. If ‘d’ is ‘0’, the result is

placed in W. If ‘d’ is ‘1’, the result is

placed in data memory

location ‘f’.

If ‘a’ is ‘0’, the Access Bank is selected.

If ‘a’ is ‘1’, the BSR is used to select the

GPR bank (default).

If ‘a’ is ‘0’ and the extended instruction

set is enabled, this instruction operates

in Indexed Literal Offset Addressing

mode whenever f

≤ 95 (5Fh). See

Section 25.2.3 “Byte-Oriented and

Bit-Oriented Instructions in Indexed

Literal Offset Mode” for details.

Words:

Cycles:

Q Cycle Activity:

Decode

Read

Process

Data

Write to

destination

Example:

ADDWFC

REG,

0, 1

Before Instruction

Carry bit =

REG

02h

4Dh

After Instruction

Carry bit =

REG

02h

50h

ANDLW

AND Literal with W

Syntax:

ANDLW

Operands:

≤ k ≤ 255

Operation:

(W) .AND. k

→ W

Status Affected:

N, Z

Encoding:

0000

1011

kkkk

Description:

The contents of W are ANDed with the

8-bit literal ‘k’. The result is placed in W.

Words:

Cycles:

Q Cycle Activity:

Decode

Read literal

‘k’

Process

Data

Write to W

Example:

ANDLW

05Fh

Before Instruction

A3h

After Instruction

03h
