Section 9 Bus Controller (BSC)

Rev. 2.00 Sep. 24, 2008 Page 216 of 1468

REJ09B0412-0200

Bit

Bit Name

Initial

Value

R/W

Description

CMF

R/(W)* Compare Match Flag

Indicates that the refresh timer counter (RTCNT) and

refresh timer constant register (RTCOR) match.

[Clearing conditions]

• When 0 is written to this bit after this bit is read as 1

with RFSHE = 0

• When CBR refresh is performed with RFSHE = 1

[Setting condition]

• When RTCNT matches RTCOR

CMIE

R/W

Compare Match Interrupt Enable

Enables or disables an interrupt request (CMI) when the

CMF flag is set to 1.

This bit is effective when refresh control is not

performed (RFSHE = 0). When refresh control is

performed (RFSHE = 1), this bit is always cleared to 0.

This bit cannot be modified.

13 to 12 RCW1

RCW0

R/W

CAS-RAS Wait Control

Select the number of wait cycles inserted between the

CAS asserted cycle and CAS asserted cycle during

DRAM refresh.

When the SDRAM space is selected, these bits do not

affect operations although they can be read from or

written to.

00: No wait cycle inserted

01: One wait cycle inserted

10: Two wait cycles inserted

11: Three wait cycles inserted



Reserved

The initial value should not be changed.
