Section 7 Interrupt Controller
Rev. 2.00 Sep. 24, 2008 Page 145 of 1468
REJ09B0412-0200
Bit
Bit Name
Initial
Value
R/W
Description
11
10
9
8
7
6
5
4
3
2
1
0
IRQ11F
IRQ10F
IRQ9F
IRQ8F
IRQ7F
IRQ6F
IRQ5F
IRQ4F
IRQ3F
IRQ2F
IRQ1F
IRQ0F
0
0
0
0
0
0
0
0
0
0
0
0
R/(W)*
1
R/(W)*
1
R/(W)*
1
R/(W)*
1
R/(W)*
1
R/(W)*
1
R/(W)*
1
R/(W)*
1
R/(W)*
1
R/(W)*
1
R/(W)*
1
R/(W)*
1
[Setting condition]
• When the interrupt selected by ISCR occurs
[Clearing conditions]
• Writing 0 after reading IRQnF = 1 (n = 11 to 0)
• When interrupt exception handling is executed while
low-level sensing is selected and
IRQn input is high
• When IRQn interrupt exception handling is executed
while falling-, rising-, or both-edge sensing is
selected
• When the DTC is activated by an IRQn interrupt,
and the DISEL bit in MRB of the DTC is cleared to 0
Notes: 1. Only 0 can be written, to clear the flag.
2. Supported only by the H8SX/1668M Group.
7.3.7
Software Standby Release IRQ Enable Register (SSIER)
SSIER selects the IRQ interrupt used to leave software standby mode.
The IRQ interrupt used to leave software standby mode should not be set as the DTC activation
source.
Bit
Bit Name
Initial Value
R/W
15
SSI15
0
R/W
14
0
R/W
13
0
R/W
12
0
R/W
11
SSI11
0
R/W
10
SSI10
0
R/W
9
SSI9
0
R/W
8
SSI8
0
R/W
Bit
Bit Name
Initial Value
R/W
7
SSI7
0
R/W
6
SSI6
0
R/W
5
SSI5
0
R/W
4
SSI4
0
R/W
3
SSI3
0
R/W
2
SSI2
0
R/W
1
SSI1
0
R/W
0
SSI0
0
R/W
