Section 11 EXDMA Controller (EXDMAC)

Rev. 2.00 Sep. 24, 2008 Page 553 of 1468

REJ09B0412-0200

11.9

Interrupt Sources

EXDMAC interrupt sources are a transfer end by the transfer counter, and an escape end interrupt

which is caused by the transfer counter not becoming 0. Table 11.7 shows the interrupt sources

and their priority order.

Table 11.7

Interrupt Sources and Priority Order

Interrupt

Interrupt Source

Interrupt

Priority

EXDMTEND0

Transfer end indicated by channel 0 transfer counter

EXDMTEND1

Transfer end indicated by channel 1 transfer counter

EXDMTEND2

Transfer end indicated by channel 2 transfer counter

EXDMTEND3

Transfer end indicated by channel 3 transfer counter

EXDMEEND0

Channel 0 transfer size error

Channel 0 repeat size end

Channel 0 source address extended repeat area overflow

Channel 0 destination address extended repeat area overflow

EXDMEEND1

Channel 1 transfer size error

Channel 1 repeat size end

Channel 1 source address extended repeat area overflow

Channel 1 destination address extended repeat area overflow

EXDMEEND2

Channel 2 transfer size error

Channel 2 repeat size end

Channel 2 source address extended repeat area overflow

Channel 2 destination address extended repeat area overflow

EXDMEEND3

Channel 3 transfer size error

Channel 3 repeat size end

Channel 3 source address extended repeat area overflow

Channel 3 destination address extended repeat area overflow

High

Low

Interrupt source can be enabled or disabled by setting the DTIE and ESIE bits in EDMDR for the

relevant channels. The DTIE bit can be combined with the DTIF bit in EDMDR to generate an

EXDMTEND interrupt. The ESIE bit can be combined with the ESIF bit in EDMDR to generate

an EXDMEEND interrupt. Interrupt sources in EXDMEEND are not identified as common

interrupts. The interrupt priority order among channels is determined by the interrupt controller as

shown in table 11.7. For detains see section 7, Interrupt Controller.
