i.MX 6DualPlus/6QuadPlus Applications Processors Industrial Products, Rev. 3, 11/2018

138

NXP Semiconductors

Package Information and Contact Assignments

6.2.2

21 x 21 mm Ground, Power, Sense, and Reference Contact

Assignments

Table 86 shows the device connection list for ground, power, sense, and reference contact signals.

Table 86. 21 x 21 mm Supplies Contact Assignment

Supply Rail Name

Ball(s) Position(s)

Remark

CSI_REXT

—

DRAM_VREF

AC2

—

DSI_REXT

—

FA_ANA

—

GND

A13, A25, A4, A8, AA10, AA13, AA16, AA19, AA22, AD4, D3,

F8, J15, L10, M15, P15, T15, U8, W17, AA7, AD7, D6, G10,

J18, L12, M18, P18, T17, V19, W18, AB24, AE1, D8, G19, J2,

L15, M8, P8, T19, V8, W19, AB3, AE25, E5, G3, J8, L18, N10,

R12, T8, W10, W3, AD10, B4, E6, H12, K10, L2, N15, R15,

U11, W11, W7, AD13, C1, E7, H15, K12, L5, N18, R17, U12,

W12, W8, AD16, C10, F5, H18, K15, L8, N8, R8, U15, W13,

W9, AD19, C4, F6, H8, K18, M10, P10, T11, U17, W15, Y24,

AD22, C6, F7, J12, K8, M12, P12, T12, U19, W16, Y5

—

GPANAIO

Analog output for NXP use only. This

output must remain unconnected

HDMI_DDCCEC

Analog ground reference for the Hot

Plug detect signal

HDMI_REF

—

HDMI_VP

—

HDMI_VPH

—

NVCC_CSI

Supply of the camera sensor interface

NVCC_DRAM

R18, T18, U18, V10, V11, V12, V13,

V14, V15, V16, V17, V18, V9

Supply of the DDR interface

NVCC_EIM0

K19

Supply of the EIM interface

NVCC_EIM1

L19

Supply of the EIM interface

NVCC_EIM2

M19

Supply of the EIM interface

NVCC_ENET

R19

Supply of the ENET interface

NVCC_GPIO

Supply of the GPIO interface

NVCC_JTAG

Supply of the JTAG tap controller

interface

NVCC_LCD

P19

Supply of the LCD interface

NVCC_LVDS2P5

Supply of the LVDS display interface

and DDR pre-drivers. Even if the LVDS

interface is not used, this supply must

remain powered.
