Boot Mode Configuration

i.MX 6DualPlus/6QuadPlus Applications Processors Industrial Products, Rev. 3, 11/2018

NXP Semiconductors

133

5.2

Boot Devices Interfaces Allocation

Table 85 lists the interfaces that can be used by the boot process in accordance with the specific boot

mode configuration. The table also describes the interface’s specific modes and IOMUXC allocation,

which are configured during boot when appropriate.

EIM_A19

Input

BOOT_CFG3[3]

EIM_A20

Input

BOOT_CFG3[4]

EIM_A21

Input

BOOT_CFG3[5]

EIM_A22

Input

BOOT_CFG3[6]

EIM_A23

Input

BOOT_CFG3[7]

EIM_A24

Input

BOOT_CFG4[0]

EIM_WAIT

Input

BOOT_CFG4[1]

EIM_LBA

Input

BOOT_CFG4[2]

EIM_EB0

Input

BOOT_CFG4[3]

EIM_EB1

Input

BOOT_CFG4[4]

EIM_RW

Input

BOOT_CFG4[5]

EIM_EB2

Input

BOOT_CFG4[6]

EIM_EB3

Input

BOOT_CFG4[7]

1 Pin value overrides fuse settings for BT_FUSE_SEL = ‘0’. Signal Configuration as Fuse Override Input at Power

Up. These are special I/O lines that control the boot up configuration during product development. In production,

the boot configuration can be controlled by fuses.

Table 85. Interfaces Allocation During Boot

Interface

IP Instance

Allocated Pads During Boot

Comment

SPI

ECSPI-1

EIM_D17, EIM_D18, EIM_D16, EIM_EB2, EIM_D19,

EIM_D24, EIM_D25

—

SPI

ECSPI-2

CSI0_DAT10, CSI0_DAT9, CSI0_DAT8, CSI0_DAT11,

EIM_LBA, EIM_D24, EIM_D25

—

SPI

ECSPI-3

DISP0_DAT2, DISP0_DAT1, DISP0_DAT0,

DISP0_DAT3,DISP0_DAT4,DISP0_DAT5,DISP0_DAT6

—

SPI

ECSPI-4

EIM_D22, EIM_D28, EIM_D21, EIM_D20, EIM_A25,

EIM_D24, EIM_D25

—

SPI

ECSPI-5

SD1_DAT0, SD1_CMD, SD1_CLK, SD1_DAT1,

SD1_DAT2, SD1_DAT3, SD2_DAT3

—

EIM

EIM_DA[15:0], EIM_D[31:16], CSI0_DAT[19:4],

CSI0_DATA_EN, CSI0_VSYNC

Used for NOR, OneNAND boot

Only CS0 is supported

Table 84. Fuses and Associated Pins Used for Boot (continued)

Direction at Reset

eFuse Name
